| Dimensions | Width, mm. | 800 – 1800 ± 1% | |
| Thickness of belt , mm | 8 – 24 | ||
| Thickness of covers, mm | On customer’s demand | ||
| Deviation from thickness belt | under 10 mm | ± 1 mm | |
| over 10 mm | ± 10 % | ||
| rubber cover | under 4 mm | – 0.2 mm / + free | |
| over 4 mm | – 5 % / + free | ||
| Length, m, |
PRODUCT CHARACTERISTICS
| Characteristics of insertions | Insertions number | 2 – 6 | ||||||||||
| Type of insertion | EP 80 |
EP 100 |
EP 125 |
EP 160 |
EP 200 |
EP 250 |
EP 315 |
EP 400 |
EP 500 |
|||
| Tensile strength, kgf, (for 50mm x 200mm) | longitudinal | 500 | 700 | 800 | 1000 | 1200 | 1500 | 2000 | 2200 | 2800 | ||
| transversal | 250 | 250 | 350 | 380 | 500 | 500 | 500 | 500 | 500 | |||
| Adhesion, kgf/cm, min. | between plies | 5 | ||||||||||
| between insertions and rubber covers | under 1.5 mm | 3.5 | ||||||||||
| over 1.5 mm | 4.5 | |||||||||||
| Edges | covered edges | |||||||||||
| Surfaces | both surfaces covered | |||||||||||
| Breaking force of conveyor belt,(kgf/cm) | It is given by the type and number of insertions | |||||||||||
| Type cover | Standard | Temperature range | Flame resistant | Carcass Mixture composition | Cover Mixture composition | |||||||
| S | DIN 22102/1-91 S | – 30….. +70 °C | Antistatic and highly inflammable belt | SBR + NR |
SBR + NR |
|||||||
| K | DIN 22102/1-91 K | – 30….. +70 °C | Antistatic belt with flame resistant covers | SBR + NR |
SBR + NR |
|||||||
THE TYPE OF RUBBER FROM COVER FACES
| Belt type | daN/cm2 | Tensile strength, min., at break, min. (%) |
Elongation max., (mm3) | Abrasion loss | Electrical resistance resistance of the surface in accordance with SR EN20284 (DIN 22104), Ώ max… |
Fire resistant product is in accordance with SR ISO 340(DIN 22103); (flame resistance time after retirement of burner); |
|||
| Group | Types | Standards | Number for each group of 6 test samples, (s), max. | Number for each tested sample, (s), max. | |||||
| 1. | S | Technical Card 720 | 150 | 400 | 200 | 3 x 10^8 | 45 *) | 15 *) | |
| 2. | K | Technical Card 654 | 150 | 350 | 200 | 3 x 10^8 | 45 **) | 15 **) | |
