Home / Rubber Sheeting / Hypalon Rubber Sheeting / Black High temperature Hypalon Rubber 65° shore
Flame Retardant Rubber

Do you need help or advice? Call 01702 548800

Item Code: SM210

Black High temperature Hypalon Rubber 65° shore

SM210 Black High temperature Hypalon Rubber 65° shore is a High quality Hypalon sheeting with outstanding resistance to chemical and oil attack at high and low temperatures.

N.B. Metroseal Sheeting can be supplied plain or with self adhesive backed tape (SAB). Rubber Strip to bespoke sizes are available along with customised sheets/gaskets. Please email your enquiry details to sales@metroseal.co.uk

  • Material Profile: See below
  • Thickness: 0.5mm to 50mm
  • Sheet Size: 1.4m wide in 5, 10 and 20m rolls
  • Finish: Smooth finish,
  • Cutting: Standard press-tools

This Product is REACH, RoHS, PAH and CE Compliant

Other grades, colours and finishes are available – subject to minimum batch quantities

PROPERTIES

TEST METHOD

VALUES FPS UNITS

TEST METHOD

VALUES METRIC UNITS

SPECIFIC GRAVITY

ASTM D297

1.40

DIN 53508

1.40

HARDNESS

ASTM D2240

65 ± 5 SH A

DIN 53505

65 ± 5 SH A

TENSILE STRENGTH ( MIN )

ASTM D412

1425 PSI

DIN 53504

100 KG/CM2

ELONGATION AT BREAK ( MIN )

ASTM D412

350%

DIN 53504

350%

COMPRESSION SET (70ºC/24 HRS/25% SET) (MAX)

ASTM D395 METHOD B



40%



DIN 53517



40%

POLYMER CONTENT:







100%

TEAR RESISTANCE ( ANGULAR ) MIN

ASTM D624

140 LBS/INCH

DIN 53515

25 KG/CM

CHANGE IN PROPERTIES









HEAT AGEING ( 72 HRS. AT 70ºC )

ASTM D573







— HARDNESS (PTS)



+ 3 (MAX)



+ 3 (MAX)

— TENSILE STRENGTH (%)



+ 10 / – 10



+ 10 / – 10

— ELONGATION AT BREAK (%)



+ 10 / – 10



+ 10 / – 10

VOLUME SWELL : AT 70ºC FOR 72 HRS/IN

ASTM D 471







ASTM OIL NO.1



+ 10%



+ 10%

ASTM OIL NO.2



+ 18%



+ 18%

ASTM OIL NO.3



+ 25%



+ 25%

POLYMER CONTENT (HYPALON)









CHEMICAL RESISTANCE









— OZONE

ASTM D 1149

EXCELLENT



EXCELLENT

— DILUTE ACIDS AND BASES



EXCELLENT



EXCELLENT

— CONCENTRATED ACIDS AND BASES



GOOD



GOOD

— OILS



GOOD



GOOD

— SOLVENTS



FAIR



FAIR

TEMPERATURE RANGE



-30 TO +180oC

COLOUR



BLACK
