Home / Rubber Sheeting / Neoprene Sheeting - Spec' Grade / 60 Shore Black High Grade Neoprene Reinforced Sheeting to BS2752 C60– 1Ply 150GSM Nylon fabric

Item Code: SM196CT

60 Shore Black High Grade Neoprene Reinforced Sheeting to BS2752 C60– 1Ply 150GSM Nylon fabric

SM196CT is a high grade neoprene reinforced sheeting generally conforming to BS2752/C60 specification reinforced with high strength 150GSM nylon fabric [1 ply as standard, multiple to special order and suitable for use with oil and water. It also has excellent resistance to flexing, anti-creep and stretching.

N.B. All Metroseal sheeting can be supplied plain or with self adhesive backed tape (SAB). Rubber Strip to bespoke sizes are available along with customised sheets/gaskets. Please email your enquiry details to sales@metroseal.co.uk

Material profile: See below:

  • Thickness: 0.5mm to 50mm
  • Sheet Size: 1.5m wide in 10m & 20m rolls
  • Finish: Smooth finish
  • Cutting: Standard press-tools

This Product is REACH, RoHS, PAH and CE Compliant

Other grades, colours and finishes are available – subject to minimum batch quantities

PROPERTIES

TEST METHOD

VALUES

METRIC UNITS

SPECIFIC GRAVITY

BS 903: PART A1

1.30

HARDNESS

BS 903: PART A26

60 ± 5 IRHD

TENSILE STRENGTH (KG/CM2)

BS 903:  PART A2

130

ELONGATION AT BREAK (MIN)

BS 903: PART A2

350%

COMPRESSION SET (70ºC/24 HRS/25% SET) (MAX)

BS 903: PART A6

25%

TEAR RESISTANCE ( ANGULAR ) MIN

BS 903:  PART A3

35 Kg/cm

RESISTANCE TO ACCELERATED AGEING- 168HRS AT 70˚C

BS 903: PART A19



— HARDNESS (Pts)

BS 903: PART A26

+ 7 (MAX)

— TENSILE STRENGTH (%)

BS 903: PART A2

-12 (MAX)

— ELONGATION AT BREAK (%)

BS 903: PART A2

-20 (MAX)

VOLUME SWELL: AT 40˚C FOR 24 HRS/IN

BS 903: PART A16



FUEL B



+ 70% (MAX)

RESISTANCE TO LOW TEMPERATURE AT –

40ºC

BS 903: PART A13

MEETS REQUIREMENTS

ADHESION TO AND CORROSION OF METALS

BS 903: PART A 37

MEETS REQUIREMENTS

POLYMER CONTENT (NEOPRENE)



100%

ADDITIONAL INFORMATION –

CHEMICAL RESISTANCE



— OZONE

BS 903: PART A 43

GOOD

— DILUTE ACIDS AND BASES

BS 903: PART A16

GOOD

— CONCENTRATED ACIDS AND BASES



NOT RECOMMENDED

— MINERAL OILS – PARAFINNIC &

NAPHTHANIC HC



GOOD

— MINERAL OILS – AROMATIC HC



FAIR

–ANIMAL/VEGETABLE OIL



GOOD

–SOLVENTS



FAIR

TEMPERATURE RANGE



-30º TO + 120º C

COLOUR

BLACK

INSERTION

1PLY 150GSM Nylon fabric reinforcement

VOLUME SWELL DATA

RESISTANCE TO LIQUIDS

BS ISO 1817, 24 h at (40±1) °C

-0

VOLUME CHANGE (%) AFTER IMMERSION IN LIQUID B

BS ISO 1817, 24 h at (40±1) °C

+70

RESISTANCE TO ACCELERATED AGEING

PART A19, AIR-OVEN METHOD A, (168±2)h, (70±1)°C

-0

CHANGE IN HARDNESS DEGREES (IRHD)

PART A26, METHOD N, MEASUREMENTS BEFORE AND AFTER AGEING ON THE SAME 2 PLIES EACH 2.00MM THICK

+7

MAXIMUM CHANGE IN TENSILE STRENGTH (% OF ORIGINAL VALUE)

PART A2, TYPE 1 OR TYPE 2 DUMBBELLS

-12

MAXIMUM CHANGE IN ELONGATION AT BREAK (% OF ORIGINAL VALUE)

PART A2, TYPE 1 OR TYPE 2 DUMBBELLS

-20
