Home / Rubber Sheeting / EPDM Rubber Sheeting / Black EPDM UL94-VO Flame Retardant Sheet 65° shore

Item Code: SM176

Black EPDM UL94-VO Flame Retardant Sheet 65° shore

SM176 Black EPDM Flame Retardant Sheet 65° shore is a High Grade flame retardant EPDM compound meeting and passing the test requirements of American standard UL94-VO test rating

Flame Resistance to DIN75200 -UL94VO – PASS

N.B. Metroseal Sheeting can be supplied plain or with self adhesive backed tape (SAB). Rubber Strip to bespoke sizes are available along with customised sheets/gaskets. Please email your enquiry details to sales@metroseal.co.uk

The above sheeting is manufactured from top quality virgin materials and ingredients meeting high standard of performance.

  • Material Profile: See below
  • Flame Retardant
  • Thickness: 0.5mm to 50mm
  • Sheet Size: 1.4m wide in 5, 10 and 20m rolls
  • Finish: Plate finish
  • Cutting: Standard press-tools

This Product is REACH, RoHS, PAH and CE Compliant

Other patterns, colours and finishes are available – subject to minimum batch quantities

PROPERTIES

TEST METHOD

VALUES FPS UNITS

TEST METHOD

VALUES METRIC UNITS

SPECIFIC GRAVITY

ASTM D297

1.40 ± 0.05

DIN 53508

1.40 ± 0.05

HARDNESS

ASTM D2240

65 ± 5 SH A

DIN 53505

65 ± 5 SH A

TENSILE STRENGTH ( MIN )

ASTM D412

711 PSI

DIN 53504

50 KG/CM2

ELONGATION AT BREAK ( MIN )

ASTM D412

200%

DIN 53504

200%

COMPRESSION SET (70ºC/24 HRS/25% SET) (MAX)

ASTM D395 METHOD B

50%

DIN 53517

50%

TEAR RESISTANCE ( ANGULAR ) MIN

ASTM D624

112  LBS/INCH

DIN 53515

20 KG/CM

CHANGE IN PROPERTIES









HEAT AGEING ( 72 HRS. AT 70ºC )

ASTM D573







— HARDNESS (PTS)



+ 5 (MAX)



+ 5 (MAX)

— TENSILE STRENGTH (%)



+ 10 / – 10



+ 10 / – 10

— ELONGATION AT BREAK (%)



+ 10 / – 20



+ 10 / – 20

VOLUME SWELL : AT 70ºC FOR 72 HRS/IN

ASTM D 471







ASTM OIL NO.1



NOT RECOMMENDED



NOT RECOMMENDED

ASTM OIL NO.2



NOT RECOMMENDED



NOT RECOMMENDED

ASTM OIL NO.3



NOT RECOMMENDED



NOT RECOMMENDED

FLAMMABILITY TEST

UL94, V-O

PASS

UL94, V-O

PASS

POLYMER CONTENT (EPDM)



100%



100%

CHEMICAL RESISTANCE









— OZONE

ASTM D 1149

EXCELLENT



EXCELLENT

— DILUTE ACIDS AND BASES



EXCELLENT



EXCELLENT

— CONCENTRATED ACIDS AND BASES



EXCELLENT



EXCELLENT

— OILS



NOT RECOMMENDED



NOT RECOMMENDED

— SOLVENTS



NOT RECOMMENDED



NOT RECOMMENDED

TEMPERATURE RANGE



-30º TO + 130ºC



-30º TO + 130ºC

COLOUR



BLACK
