Item Code: SM218BL

Black Diamond Drum Lagging – Mini Diamond With Neoprene Bonding Layer

Black Diamond Drum Lagging – Mini Diamond is a high abrasion resistant rubber sheet material particularly suitable Drum Lagging, It is a Natural Rubber Rubber with a hardness of 65° shore.

Supplied with a Neoprene Bonding Layer

On most sheetings we can offer the additional benefits of:-

Tacky – Back A bonding layer applied to one surface
Dry – Back Heavy Duty EP fabric layer on one or both sides
PU – Face A 2 or 3mm polyurethane coated surface layer

The above sheeting is manufactured from top quality virgin materials and ingredients meeting high standard of performance

  • Material Profile: See below
  • Thickness: 6.0mm to 55mm
  • Sheet Size: 1.5m wide or 2,0m wide
  • Finish: Plate finish
  • Cutting: Standard press-tools (full steel construction advised)

This Product is REACH, RoHS, PAH and CE Compliant

Other grades, colours and finishes are available – subject to minimum batch quantities

Technical Data

Stock Roll Sizes [m x m x mm]Surface FinishWeight [kg/M2]
6.0mm x 1500mm x 10m 7,02
8.0mm x 1500mm x 10m 9.36
10.0mm x 1500mm x 10 11.70
12.0mm x 1400mm x 5m 14.04
15.0mm x 1500mm x 5m 17.55
Specifications CompoundValues [typical]
Colour: Black
Compound:: NR
Density [specific gravity]: 1.17
Hardness [Degrees Shore A]: 65° ± 5°
Tensile Strength Kg/cm2 [Polymer]: 115
Elongation at break: 450
Minimum Temperature: -30°C
Maximum temperature: +70°C
Abrasion resistance [mm3]: 120
Compression Set (70°C for 22 hours) %:
