Gas Balloon & Pillow Tank Fabric

SKU: MCF-Pillow-Tank
Roll Size: 10m

This product is available for bespoke manufacturing, please choose an option below:

Select Options

  • This has anti capillary quality which is used for Diaphragm Valve’s Application
  • It can be easily used at 110°c temperature
  • It also can be used in experimental floats in Defense
  • Available in different colours, sizes and thicknesses
SPECIFICATION
Insertion Fabric Nylon / polyester
Polymer Neoprene / Hypalon
Colour Black / Orange / Red / Grey
Breaking Strength Warp- 500 kgs, Weft- 450 kgs,
Warp- 1102 lbs, Weft- 992 lbs
Min. Thickness 1.0 mm ± 0.05 mm, 0.039 inch
± 0.002” & 1.20 mm ± 0.05 mm, 0.047 inch
± 0.002”
Width Available 1.0 Mtr (39.37”) to 2.0 Mtr (78.74”)
Coated Fabric Weight GSM 1300 ± 150 & GSM 1500 ± 150
